The Victron Phoenix Smart IP43 Charger 24/16(3) is a mains-powered battery charger for 24V battery banks, with three independent outputs for charging separate banks from a single unit. It suits installers working on marine, vehicle and off-grid systems where more than one battery bank needs attention at once.

Key features of the Victron Phoenix Smart IP43 charger

• Output, 24V at 16A total charge current, split across three independent outputs.
• Enclosure rating, IP43, protecting against solid objects over 1mm and water spray up to 60 degrees from vertical.
• Connectivity, Bluetooth via the VictronConnect app, for monitoring and configuration without extra hardware.
• Charging algorithm, seven-stage adaptive charging with battery-safe absorption and float stages.
• Battery compatibility, lead-acid types including AGM, Gel and flooded, plus lithium (LiFePO4).
• AC input, 230V, suited to standard UK and European single-phase supply.

How the charging process works

A microprocessor-controlled algorithm monitors battery response during the absorption phase and adjusts charge time accordingly, which reduces stress on the battery compared with a fixed-time charge. The seven stages cover bulk, absorption, float, storage and a periodic equalisation cycle for lead-acid types.

Bluetooth means the charger can be set up and checked from a phone or tablet through VictronConnect, useful where the unit sits somewhere awkward to reach. Charge profiles, presets and live voltage and current readings are all available without a separate interface cable.

Applications

Each of the three outputs is managed independently, so current is allocated according to the state of each connected battery rather than shared equally. That makes it a practical fit for a vessel with a starter and service battery, a motorhome with multiple 24V banks, an off-grid cabin with mains hook-up, or a commercial vehicle with auxiliary 24V batteries.

Installation notes

This charger needs a 230V AC mains supply and should be installed by someone familiar with battery systems and DC wiring. The AC supply should be protected by a correctly rated circuit breaker, and DC output cabling sized for the charge current and cable run. Confirm battery chemistry before selecting a charge profile.

What's in the box

• 1x Victron Phoenix Smart IP43 Charger 24/16(3) 230V
