The Victron Energy Isolation Transformer 8000W 230V gives galvanic isolation between shore power and onboard or site electrical systems. It is built for marine, mobile and off-grid installations where eliminating earth leakage currents and protecting against electrolytic corrosion matters. At 8000W continuous capacity, it suits larger vessels, vehicles and commercial installations.

Key features of this victron isolation transformer

• Power rating, 8000W continuous at 230V AC, suitable for high-load applications.
• Galvanic isolation, breaks the direct electrical connection between shore earth and onboard systems.
• Corrosion protection, reduces stray current corrosion risk on metal hulls, fittings and underwater gear.
• Core design, toroidal transformer core for low electromagnetic interference and high efficiency.
• Enclosure, steel housing built for demanding installation environments.
• Weight, 28.17 kg.

How it works

An isolation transformer couples the shore supply to the onboard system magnetically, without a direct electrical connection. This breaks the galvanic circuit that would otherwise let DC stray currents flow through the water between a vessel's hull and the marina earthing system. Left unchecked, those currents cause rapid electrolytic corrosion of propellers, shafts, anodes and through-hull fittings.

At 8000W, this unit carries the full electrical load of a well-equipped vessel or large vehicle installation, including air conditioning, battery chargers and general AC loads running together. The toroidal core keeps no-load losses low and limits the magnetic field radiated into the surrounding space, which matters in a confined bilge or locker. It operates at 230V, suited to European and UK shore power supplies.

Unlike a galvanic isolator, which only blocks DC, a full isolation transformer also protects against AC faults on the shore supply reaching the onboard system. That makes it the preferred choice where both electrical safety and corrosion protection are required.

Applications

• Marine vessels connected to marina shore power where galvanic corrosion protection is required.
• Large motorhomes, coaches and commercial vehicles with shore power connections.
• Off-grid and hybrid systems needing electrical isolation between generator or grid input and the local distribution board.
• Commercial and industrial installations needing earth loop separation between supplies.
• Installations pairing Victron MultiPlus or Quattro inverter/chargers where shore isolation is specified.

What's in the box

• 1 x Victron Energy Isolation Transformer 8000W 230V

Installation notes

Fit this transformer via a qualified electrician or marine electrical engineer. Connections to shore power, onboard distribution boards and earthing systems must comply with applicable wiring regulations, including BS 8450 for UK marina installations. The unit weighs 28.17 kg and needs secure mechanical mounting in a dry, ventilated location, away from flooding or direct water ingress. Check any relevant G98 or G99 requirements if connected to a grid-tied system.
