The Victron EasySolar 24/1600/40-16 is an all-in-one solar inverter charger combining a 1600VA inverter, a 40A MPPT solar charge controller and a 16A mains charger in one wall-mounted unit. Built for 24V battery systems, it suits off-grid homes, cabins, boats and self-consumption installations where space is limited and simple wiring matters. One enclosure replaces three separate devices and the inter-wiring between them.

Key features of the Victron EasySolar 24/1600/40-16

• Integrated design, 1600VA pure sine wave inverter, 40A MPPT charge controller and 16A battery charger in a single unit.
• MPPT 100/50, accepts up to 100V open-circuit PV voltage and delivers up to 50A charge current to the battery bank.
• Battery voltage, 24V nominal, supporting a range of chemistries including lead-acid and lithium.
• AC output, 230V, suitable for standard UK and European loads.
• PowerControl and PowerAssist, limits mains input draw and draws from the battery to cover demand peaks.
• Monitoring, VE.Direct port for use with Victron GX devices or the VictronConnect app.
• Weight, 15.37 kg.

Product overview

The MPPT 100/50 controller handles PV arrays with open-circuit voltages up to 100V, suiting small to medium string configurations. Its 50A maximum charge current is matched to 24V battery systems, giving reasonable solar harvest without oversizing the battery bank.

PowerControl monitors available mains current so the combined load of charger and connected AC loads doesn't exceed the shore or generator supply limit. PowerAssist goes further, drawing on the battery to cover short demand spikes that might otherwise trip a breaker or overload a small generator. Both functions are configurable, useful where mains supply is limited or a generator handles backup charging.

VE.Direct connectivity allows integration with Victron GX devices such as the Cerbo GX for monitoring, data logging and remote access. Configuration runs through the VictronConnect app over Bluetooth, using a VE.Direct Bluetooth Smart dongle, or directly via a GX device, so commissioning doesn't require a laptop on site.

Applications

• Off-grid residential installations with 24V battery banks and a small to medium PV array.
• Holiday homes, cabins and rural properties needing a self-contained solar and backup charging system.
• Marine and narrowboat installations where a compact all-in-one unit saves space.
• Self-consumption systems with generator or mains backup using PowerControl to manage input limits.
• Remote telecoms or monitoring sites needing 230V AC from solar with battery storage.

What's in the box

• Victron EasySolar 24/1600/40-16 230V MPPT 100/50 unit.

Installation notes

Installation should be carried out by a qualified electrician or accredited installer familiar with battery-based solar systems, connected to a 24V battery bank of appropriate capacity. PV array open-circuit voltage must not exceed 100V under any conditions, including cold weather. Grid-connected or export installations may require G98 or G99 compliance and a DNO notification.
