This current transformer measures AC current for the Victron MultiPlus-II inverter/charger, giving accurate readings for energy monitoring and system management. Its 100A:50mA ratio and 20 metre wire-end cable make it suitable for installations where the measuring point sits well away from the inverter or GX device.

Key features

• Ratio, 100A:50mA, producing a 50mA output signal for every 100A on the measured conductor
• Cable length, 20 metres, for routing between a distribution board and the MultiPlus-II or GX device
• Termination, wire-end, so the installer makes the final connection at the enclosure
• Weight, 0.7 kg
• Clamp-style sensing, fits around an existing AC conductor without breaking the circuit
• Compatibility, designed for use with the Victron MultiPlus-II inverter/charger range

How it works

The transformer induces a proportional secondary current from the magnetic field around the conductor passing through its core. The MultiPlus-II or a connected GX device uses this signal to calculate real-time current and power, without any direct electrical connection to the circuit being measured. That keeps isolation intact and simplifies installation.

Applications

Used for AC current monitoring in MultiPlus-II ESS installations, grid import/export measurement in solar-plus-storage systems, load sensing for self-consumption or peak-shaving control, and generator current monitoring in off-grid setups. The 20 metre cable suits systems where the measurement point is some distance from the inverter.

What's in the box

• 1 x Current Transformer 100A:50mA with 20 metre wire-end cable

Installation notes

Fit by a qualified electrician only, for use with the Victron MultiPlus-II and compatible GX devices. The transformer must go around a single AC conductor, not a twin or multicore cable, for correct readings. In grid-connected systems, installation must meet G98 or G99 requirements as applicable, and the receiving device's input specification should be checked before the wire-end connection is terminated.
