The Victron Blue Smart IP67 24/12 is a single-output battery charger for 24V battery banks, delivering 12A of charge current. It comes fitted with a UK BS 1363 mains plug for direct 230V connection, and the sealed IP67 enclosure makes it suitable for marine, automotive and off-grid installations where moisture or dust ingress is a concern.

Key features of the Victron Blue Smart charger

• Enclosure rating, IP67, dust-tight and protected against temporary immersion up to 1 metre.
• Connectivity, built-in Bluetooth for monitoring and configuration via the VictronConnect app on iOS or Android.
• Charging algorithm, adaptive 7-stage process covering bulk, absorption, float, storage, equalisation and recondition modes.
• Battery compatibility, works with 24V lead-acid types (AGM, gel, flooded) and lithium LiFePO4 with correct configuration.
• Output, single output, 12A continuous charge current for 24V battery banks.
• Mains input, 230V AC with a UK BS 1363 plug fitted as standard.

Temperature-compensated charging is available when paired with an optional Victron temperature sensor. The construction is compact and fully sealed, suited to permanent or semi-permanent installation in harsh environments.

Product overview

The IP67 rating separates this charger from standard workshop units. It withstands submersion in up to one metre of water for 30 minutes, so it can be fitted in bilge areas, underseat vehicle spaces or outdoor enclosures without an additional protective housing.

Bluetooth is built into the unit itself. An installer views charge status, adjusts battery presets and reviews history through VictronConnect, with no separate display or hardware needed. For lithium batteries, select the correct preset in the app before use.

The 7-stage algorithm runs the full charge cycle from bulk through to long-term storage, dropping to a storage voltage after float to reduce grid consumption and protect the battery during idle periods.

Applications

• 24V battery banks on narrowboats, sailing vessels and motorboats in bilge or wet-area locations.
• 24V service batteries in commercial vehicles, vans and HGVs during periods of inactivity.
• Off-grid cabins and outbuildings exposed to condensation or temperature swings.
• Backup battery maintenance for telecoms, security and industrial equipment on 24V systems.
• Workshop or yard charging of 24V traction or leisure batteries where a sealed unit is preferred.

Installation notes

Connect the fitted BS 1363 plug directly to a standard UK 230V socket. DC connections to the battery should use appropriately rated cable and fusing per the battery manufacturer's guidance. Lithium installations require the correct preset set in VictronConnect before the charger is put into service. The IP67 rating gives strong protection, but the unit should still be mounted somewhere ventilated rather than in a sealed, airless box. A qualified auto-electrician or marine electrician should carry out permanent vehicle or marine DC wiring.

What's in the box

• 1x Victron Blue Smart IP67 24/12 charger with integrated UK BS 1363 mains plug
