The Victron Inverter 48/500 is a 500VA pure sine wave inverter built for 48V DC battery systems. It converts stored energy into 230V AC output through a SCHUKO socket, making it a compact choice for off-grid, mobile and backup power setups that need a small, reliable AC supply from a 48V bank.

Key features

• Output, 500VA continuous, 230V AC pure sine wave from a 48V DC input.
• Communication, VE.Direct port for monitoring via Victron GX devices or the VictronConnect app.
• AC socket, SCHUKO output for direct connection of standard European loads.
• Weight, 4.1 kg, suited to space-constrained installs.
• Protections, low battery voltage shutdown, overload and over-temperature cut-out.

Product overview

The 48/500 sits at the entry point of Victron's VE.Direct inverter range. It takes a 48V nominal battery input and produces a clean 230V AC sine wave, so it works with sensitive electronics as well as standard appliances within its power rating. The SCHUKO socket lets you plug a load straight in, without extra wiring to a distribution board.

The VE.Direct port is the main way to see what the inverter is doing. Connect it to a Cerbo GX or other GX device for system-level monitoring, or to a laptop or phone through a VE.Direct to USB cable and VictronConnect. That gives an installer visibility of operating state, input voltage and fault conditions remotely.

At 500VA this unit suits individual loads such as lighting circuits, small tools, charging gear or low-draw appliances. It is not intended for high-current loads like kettles, immersion heaters or motor-start equipment. Match the load to the continuous rating for reliable operation.

Applications

• Off-grid cabins and outbuildings running a 48V battery bank.
• Marine and narrowboat systems on 48V DC needing occasional 230V AC.
• Backup power for routers, lighting or communications equipment.
• Vans and trucks with a 48V house battery.
• Small solar storage systems where one AC outlet is enough.

Installation notes

Connect directly to a 48V DC battery bank with DC cable and fusing sized for the current draw at 48V. The SCHUKO output allows direct plug-in use, but a fixed installation should be wired by a qualified electrician. This inverter is not grid-connected, so G98 or G99 notification does not apply. VE.Direct accessories such as a USB interface cable are sold separately and are needed for VictronConnect on a PC or Mac.

What's included

• Victron Inverter 48/500 230V VE.Direct SCHUKO unit
