This Victron VE.Direct Cable is a 3-metre data cable with a right angle connector on one side, built for connecting Victron Energy devices that use the VE.Direct communication port. The right angle end suits panel-mounted or recessed equipment where a straight plug would create a bend or put strain on the port.

Key features

• Length, 3 metres, giving reach between devices and monitoring equipment.
• Connectors, one straight VE.Direct connector and one right angle VE.Direct connector.
• Compatibility, works with any Victron device fitted with a VE.Direct port, including BMV battery monitors, SmartSolar MPPT controllers and Phoenix inverters.
• Function, carries serial communication data only, not power.
• Weight, 0.105 kg.

Product overview

VE.Direct is Victron's own serial communication protocol used across much of their product range. This cable links a VE.Direct-equipped device to a GX device, a VE.Direct to USB interface, a VE.Direct Bluetooth Smart dongle, or a similar accessory. It is a data-only cable and does not carry power to the connected equipment.

The right angle connector suits installations where the VE.Direct port faces a wall, panel surface or enclosure side, since a straight plug would either fail to fit or apply sideways force on the connector over time. The straight end fits the monitoring or interface device in the usual orientation. At 3 metres it covers most cabinet and wall-mounted layouts without excess slack.

Applications

• Connecting a SmartSolar MPPT charge controller to a Cerbo GX or Venus GX in a wall-mounted enclosure.
• Linking a BMV-700 or BMV-712 battery monitor to a Color Control GX where the port orientation calls for a right angle connector.
• Connecting a Phoenix inverter to a VE.Direct to USB interface for PC-based monitoring.
• Any VE.Direct run parallel to the device face where a straight connector would create a sharp bend.

What's in the box

• 1 x VE.Direct Cable, 3m, one right angle connector and one straight connector

Installation notes

Make sure both VE.Direct ports are unpowered before connecting. The connector is keyed and should seat firmly without force. This cable is not for power delivery. For commissioning work on grid-tied inverters or high-voltage battery systems, use a qualified electrician or MCS-accredited installer.
