The Victron Skylla-TG 48/25(1) is a transformer-based 48V battery charger rated at 25A continuous output, built for off-grid, marine and industrial systems that need dependable high-current charging from a 230V single-phase AC supply.

Key features of this marine battery charger

• Output, 48V at 25A continuous, up to 1,200W of charge power.
• AC input, single-phase 230V with wide input voltage tolerance.
• Charge algorithm, adaptive 4-stage: bulk, absorption, float and storage.
• Temperature compensation, available via an optional sensor to protect battery life.
• Enclosure, compact, wall-mountable, weighing 5.5 kg.
• Compatibility, works with Victron VE.Bus and optional system monitoring interfaces.

Built for demanding AC conditions

Unlike switch-mode chargers, the Skylla-TG's transformer-based design gives galvanic isolation and tolerates poor or unstable mains, which suits generator-fed systems, shore power connections and industrial sites where AC quality varies. Lead-acid chemistries including AGM, gel and flooded batteries are all supported.

The adaptive charge algorithm adjusts absorption time based on the previous discharge, cutting unnecessary gassing and helping battery life. Storage mode drops the voltage to a low maintenance level when a battery sits connected without cycling for long periods. The (1) designation refers to the unit's parallel output configuration, allowing two Skylla-TG 48/25 units to be combined for higher charge current.

Applications

• Off-grid 48V battery banks needing high-current charging.
• Marine vessels with 48V house battery systems on shore power or generator supply.
• Industrial and telecoms backup power installations.
• Generator-fed charging where AC input quality is inconsistent.
• Parallel charging with a second Skylla-TG 48/25 unit for increased output.

What's in the box

• 1x Victron Skylla-TG 48/25(1) 230V battery charger

Installation notes

Install with a qualified electrician, in line with current wiring regulations (BS 7671 in the UK) and any applicable marine electrical standards. Allow adequate ventilation around the unit during operation. The temperature sensor and monitoring accessories are sold separately.
