Certification: CE

Certification: FCC

Origin: CN(Origin)

Model Number: S4-600W

is_customized: Yes

Type: Wind Power Generator

Commodity: 5 blades wind turbine

Rated Power: 600W

Rated Voltage: 12V or 24VAC

Rotor Diameter: 1700mm

Rated Rotate Speed: 400r/min

Start Wind Speed: 2m/s

Rated Wind Speed: 8m/s

Cut-out Wind Speed: 50m/s

Life-span: 20 years

Product Features

1. 2m/s low wind speed starts the wind turbine generator.

This is the most obvious advange of this wind generator in all of same level product on the market which make high wind energy utilization rate.

2. Three phase AC output

Three phase output can make wind turbine transfer more wind power to electricity. 12V or 24V AC for customers' choise for their system.

3. Low fault and strong ability to resist the Typhoon

Fan adopts the unique design of the fuselage shock smooth operation, no noise, the blades with nylon composite materials manufacturing and become, with the optimization of aerodynamic design and structural design, start wind speed is low, high wind energy utilization coefficient, increase the power generating capacity. Stern rudder adopts the design of automatic yaw, stronger ability to resist the typhoon, safe and reliable operation.

4. Horizontal shaft function.

The wind turbine generator can adjust the angle automatically according to the wind directions by the horizontal shaft design.

5. 20-year long service life.

Due to the motor internal labyrinth design, external all fasteners are high strength stainless steel products, so it has better protection effect, can waterproof (IP65), prevent sand more effectively.

6. Structure is simple and reliable, beautiful appearance, strong mobility.

7. easy installation

Datasheet

Power

Rated power

600W

600W

600W

600W

Maximum power

610W

610W

610W

610W

Rated voltage

12/24V

12/24V

12/24V

12/24V

SKU

3S4-600-D

5S4-600-D

3S4-600

5S4-600

Blades

Blades Length

63cm/25inch

65cm/26inch

Wheel Diameter

135cm/53inch

140cm/55inch

Blades material

High-strength nano-fiber glass fiber

reinforced plastic material design life 15 years

Optional colors

White(default)/Black/Blue/Red/Green/Orange/Yellow/mixed colors

Shape

Delta wing

Ordinary

Blades QTY

3 PCS

5 PCS

3 PCS

5 PCS

Wind

Start-up

2m/s

1.8m/s

2m/s

1.8m/s

4.5mph

4mph

4.5mph

4mph

Rated speed

11m/s

10m/s

11m/s

10m/s

25mph

22mph

25mph

22mph

Survival speed

48m/s

45m/s

48m/s

45m/s

107mph

100mph

107mph

100mph

Generator

Type

3 phase permanent magnet synchronous(NdFeB) AC generator

Case

Die-casting aluminum

Control system

Electromagnet

Speed regulation

Automatically adjust windward direction

Operation

-40°C- + 80°C

Connector

Hoop(default), Flange to connect with tower pole

Design life

20 Years

Suggest

Cables

Copper 3 core wind AC cable, waterproof and UV resistant

Tower Pole

6 meter hight with Steel cable

Others

Approved

CE, ROHS, FCC, ISO, BIWEI

SKU

3S4-600-D

5S4-600-D

3S4-600

5S4-600

G.W

10KGS

10.5KGS

10KGS

10.5KGS
