This T5 LED Tube from Ledison replaces a fluorescent T5 fitting with a dimmable 12W LED alternative, 863mm pin to pin (90cm), producing 1440lm. It ships with rotatable end caps and a choice of 120 or 140 degree beam angles, and runs at 125lm/W efficiency.

Key features of this dimmable T5 LED tube

• Output, 1440lm from 12W, at a stated efficiency of 125lm/W.
• Dimming options, AC Triac 25W dimmable driver for trailing and leading edge dimmer switches, with on-board dip-switches to adjust full power from 18W to 25W.
• 1-10V control, EASEIC 1-10V slim aluminium power supply, compatible with analogue dimmer switches via an external twisted pair cable, adjusting luminosity in 10% steps up to 100%.
• DALI compliant, EASEIC DALI driver certified to the DALI protocol, compatible with DALI controllers on the market.
• Lifespan, rated for 50,000 hours of continuous operation while keeping a consistent lumen output.
• Warranty, 5-year warranty policy.
• End caps, rotatable, with a choice of 120 or 140 degree beam angle.

Applications

Suited to retrofitting existing T5 fluorescent fittings in offices, retail units, and commercial spaces where dimming control is needed, whether through a trailing/leading edge wall dimmer, a 1-10V analogue system, or a DALI lighting control network.

Build quality

Ledison builds this tube with quality materials and assembles it by hand, backing it with the 5-year warranty and the 50,000 hour rated lifetime.
