Our 60A MPPT Charge Controller With Bluetooth is the most efficient type of charge controller. With up to 99% tracking efficiency, it ensures maximum power point solar charging that gets more energy to your battery bank. Capable of automatically detecting 12V/24V/36V/48V lead acid battery systems, this crucial component is preset to also work With Gel, Flooded (wet cell), Sealed, and even Lithium batteries.

Features:
With up to 99% tracking efficiency, it ensures maximum power point solar charging that gets more energy to your battery bank.
Capable of automatically detecting 12V/24V/36V/48V lead acid battery systems, this crucial component is preset to also work With Gel, Flooded (wet cell), Sealed, and even Lithium batteries.

Specifications:

Input :
Maximum PV open circuit voltage: 150V (at the lowest temperature) and 138V (at a standard temperature of 25°C)
Minimum PV voltage: 20V/40V/60V/80V
Rated Charge Current: 60A
Maximum input power:
12V: 780W
24V: 1560W
36V: 2340W
48V: 3120W

Output:
System voltage: 12V/24V/36V/48VAuto
Rated Discharge Current: 30A
Self-consum: <35mA(48V)
MPPT's highest accuracy: 99%
Maximum charging efficiency: 97%
Charging control mode: Multi-stage(MPPT, Absorption, Float, Equalization, CV)
Low voltage recovery voltage:
12.6V/25.2V/37.8V/50.4V
Load control mode: Normal, light control, light and timing control, timing control, reverse light control
Light control point voltage: 5V/10V/15V/20V

Other:
Human interface: Color LCD with backlight, 3 buttons
Cooling mode: Iron case heat sink and cooling fan
Wiring: High current copper terminal≤25 mm²(3AWG)
Temperature probe:10K, line length 3 meters
Communication mode: RS485, RJ45 port
Working temperature range: -20~+55°C
Storage temperature range: -30~+80°C
Humidity: 10%~90% No condensation

Dimension & Weight:
Size: 265mmx220mmx88mm
Weight: 3.3KG

Package:
1x solar controller
