This 24V power supply delivers a 36W constant voltage output for LED strip lights, low voltage LED bulbs and small 24V DC lighting installations. The GP-CVP036N-24V-T12 provides 24V DC output at up to 1.5A, suitable for cabinet lighting, display lighting and decorative LED runs.

24V power supply for LED strip lighting

Constant voltage design keeps the output steady for 24V LED products that need a stable DC feed. Check the wattage per metre of any LED strip before wiring it in: this unit can carry loads up to 36W in total, which covers around 5 metres of 7.2W per metre strip provided the combined load stays within the rated output.

Key features

• Output, 24V DC constant voltage, up to 1.5A
• Rated power, 36W
• AC input, 90-264VAC universal range
• Class II design, fully isolated plastic case, no earth connection required
• Protection, over current, short circuit, over temperature and over voltage
• No load consumption, under 0.5W at 230VAC
• Wiring, 2P screw terminal blocks on input and output

Applications

Fits 24V LED strip lights, under cabinet lighting, retail display lighting, shelf and showcase lighting, decorative low voltage LED lighting, and low voltage LED bulbs that need a 24V DC constant voltage input.

Installation notes

• Use only with compatible 24V LED products.
• Do not exceed the 36W rated output.
• Check the total wattage of the connected LED strip or circuit before wiring.
• Allow ventilation around the driver and avoid covering it with insulation.
• Fit by a qualified person in line with current wiring regulations.
