Description
Extend Your Solar System with High‑Power TBB Solar Mate SP600‑120 MPPT Charge Controller
The Solar Mate SP600‑120 is a high‑voltage, transformer‑isolated MPPT charge controller designed to convert solar energy into electricity for 48 V lithium or lead‑acid batteries. With a 600 V open‑circuit PV input and dual independent MPPT trackers, it maximises solar harvest while reducing balance‑of‑system costs. High conversion efficiency (≈97 %) and robust safety mechanisms make it ideal for off‑grid, hybrid and energy‑storage applications.
Key functions:
1. High‑voltage & wide MPPT tracking: The wide 80–525 V MPPT range minimises the need for a combiner box and allows greater system flexibility.
2. Dual independent MPPT trackers: Two separate trackers allow different roof orientations or arrays, optimising energy harvest.
3. High electrical safety & isolation: Reinforced insulation between the PV and battery sides and built‑in earth‑fault detection improve safety and reliability.
4. Superior efficiency & compact design: Overall efficiency up to 97 % reduces energy losses while the compact housing saves space.
- Smart cooling system: intelligent fan control minimises noise while optimising thermal management.
- User‑friendly interface: LCD display and LED indicators provide real‑time system insights:contentReference.
- Advanced monitoring & communication: RS485, CAN bus and Bluetooth app support allow seamless monitoring and control.
- Programmable relay & dry contact: includes one programmable relay (dry output) and one dry input for custom integration.
- Parallel capability: supports parallel connection of up to 15 units for higher power capacity.
- Battery compatibility & grounding: supports lead‑acid and lithium batteries with CAN bus communication; the positive battery pole grounding meets telecommunication standards.
- Versatile applications: suitable for residential and commercial energy storage, off‑grid and hybrid systems, telecommunication backup power and remote energy solutions.
Controller specifications:
- Nominal battery voltage: 48 V.
- Maximum charge current: 120 A
- Maximum charge power: 7000 W @57.6 V total (5000 W per tracker).
- Maximum PV open‑circuit voltage: 600 V
- PV operating voltage range: 120–525 V
- MPPT voltage range: 80–525 V
- Number of MPPT trackers: 2
- Maximum PV input current per tracker: 18 A
- Maximum PV power per tracker: 8000 W
- MPPT efficiency: >99.9 %
- Maximum conversion efficiency: ≈97 %
- Operating temperature range: –20 °C to +65 °C
- Dimensions (approx.): 484 × 280 × 108 mm
- Weight: 7.8 kg
The product is covered by a 5‑year warranty.
The product includes a detailed user manual covering wiring and operation.
Documents available for download:
User Manual for TBB Power Solar Mate SP600 48V 120A MPPT solar charge controller (SP600-120)
Datasheet for TBB Power Solar Mate SP600 48V 120A MPPT solar charge controller (SP600-120)
