Introducing the SolaX TSYS-HS51 Battery System

Choosing the TSYS-HS51 battery offers numerous advantages, including high performance with rapid charging and discharging, stability with an IP66 rating and LFP cells for long-term reliability, and flexibility in capacity expansion. It supports both single-phase and three-phase inverters, making it compatible with residential, commercial, and industrial applications. Its compact, stackable design ensures easy installation, and its versatile connection options enhance output and performance. These features make it an ideal choice for efficient and reliable energy storage solutions.

Key Features:

• High Flexibility: Revolutionise your energy storage with the modular design of the SolaX HS51 battery, offering flexible capacity options in 5.1kWh increments. Say goodbye to external wiring as modules effortlessly plug together. The battery stack comprises:
  • Battery Management System (BMS) TBMS-S51-8: The brain of the system, controlling the entire battery operation.
  • Battery Module TP-HS51: Rechargeable 5.1kWh power packs, building up capacity in convenient blocks. With a 90% depth of discharge, each module provides 4.59kWh of usable load.

  • Base Module: Providing sturdy support on the ground.
  • Series Box: Construct a battery stack with ease, comprising the BMS, battery modules, and base in one (2-8 battery modules) or two towers with up to 13 battery modules in total. For connecting two towers, a Series Box is necessary.
• Fast Charging and Discharging: The TSYS-HS51 supports fast charging and discharging with a maximum current of 70A, ensuring high-power output during peak demand and efficient energy management.
• Backup Functionality: Rest assured during grid blackouts with the Triple Power T-BAT-SYS-HV-S5.1 battery, ready to provide emergency backup power for your home. Teaming up seamlessly with the SolaX X1 (single phase) or X3 (three phase) hybrid inverter, it swiftly switches to emergency power mode upon detecting grid voltage loss. Maintain a minimum 25% state of charge for uninterrupted backup.
• Scalability: For X1-HYBRID G4 or X1-FIT G4 inverters: 2~8 batteries can be installed to achieve 10.2kWh ~ 40.9kWh with one tower/stack installation. For X3-HYBRID G4 or X3-FIT G4 model: 3~13 batteries can be installed to achieve 15.3kWh ~ 66.5kWh. Series Box shall be needed for two tower installation.
• Adding Capacity After Installation: Adapt to evolving energy needs effortlessly with the modular SolaX TSYS-HS51 battery, allowing capacity expansion post-installation. If you find out your customer needs more batteries, adding new modules is as easy as shifting a few modules and locking additional modules in place! When adding modules, follow the stacking and installation requirements outlined in the user manual, including proper orientation, wiring, and safety precautions
• Warranty: Ensure safety with SolaX's proven technology, certified to global standards. Enjoy peace of mind with a comprehensive 10-year warranty and a design life of 6000 cycles.
• Prompt Delivery: Elevate your energy storage capabilities with SolaX's efficient solution, delivered promptly within 2-3 working days across the UK (extended delivery times to the Highlands, islands, and Northern Ireland).

Power up your energy storage capabilities with SolaX's reliable and efficient solution.
