Description
The SLD Tech (Solarland) ST-255Q-24CID2-QC is a 255-watt, 72-cell monocrystalline solar panel delivering 22% module efficiency, certified for Class I, Division 2 hazardous locations for reliable 24V DC power in industrial, oil and gas, and remote energy applications.
Key Features:
- Class I, Division 2 Certified: cULus listed and compliant with NFPA and NEC safety standards for use in environments at risk of gas explosions, with specialized design elements minimizing ignition risk in hazardous locations.
- High-Efficiency 22% Monocrystalline Cells: Advanced cell technology and manufacturing capabilities achieve 22% module efficiency with a 3% positive power tolerance for consistent, reliable output in safety-critical applications.
- Heavy-Duty Weather-Resistant Construction: Anodized aluminum frame withstands 5,400 Pa positive load and 2,400 Pa negative load, with salt mist resistance per IEC 61701 for coastal and high-exposure installations.
- High-Transparency Tempered Glass: Low-iron tempered glass maximizes light transmission while providing outstanding protection against hail, wind pressure, and heavy snow.
- 25-Year Power Warranty: Backed by a 25-year linear power output warranty and a 10-year product workmanship warranty for reliable long-term performance assurance.
The ST-255Q-24CID2-QC is designed for nominal 24V DC output in demanding industrial environments where standard panels are not permitted. Its CID2 certification makes it the ideal solution for oil fields, refineries, chemical plants, mining operations, and other hazardous area power systems requiring dependable high-wattage solar energy.
Built with 72 monocrystalline silicon cells in a 4x18 configuration, this panel is engineered for durability and reliability in volatile and hazardous conditions where both safety and efficiency are critical. The 33.46 lb design and 1.57-inch profile are built to withstand the mechanical stresses of demanding industrial field installations.
With an operating temperature range of -40°C to 65°C and a maximum system voltage of 600V DC, the ST-255Q-24CID2-QC meets the strict rating requirements of Class I, Division 2, Groups A, B, C, and D hazardous locations.
Technical Specifications
| Specification | Details |
|---|---|
| Weight | 33.46 lbs (15.18 kg) |
| Maximum Power (Pmax) | 255W |
| Module Efficiency | 22% |
| Voltage at Pmax (Vmp) | 40.59V |
| Current at Pmax (Imp) | 6.28A |
| Open-Circuit Voltage (Voc) | 47.09V |
| Short-Circuit Current (Isc) | 6.61A |
| Power Tolerance | ±3% (0~±3%) |
| STC Test Conditions | 1000W/m², AM1.5 Spectrum, 25°C |
| Temperature Coefficient of Voc | -(80±10) mV/°C |
| Temperature Coefficient of Isc | (0.065±0.015) %/°C |
| Temperature Coefficient of Power | -(0.5±0.05) %/°C |
| NOCT | 47±2°C |
| NOCT Test Conditions | Air 20°C, Sun 0.8kW/m², Wind 1m/s |
| Operating Temperature | -40°C to 65°C |
| Maximum System Voltage | 600V DC |
| Cell Type | Monocrystalline Silicon |
| Cell Configuration | 72 Cells (4 x 18) |
| Frame Material | Heavy-Duty Anodized Aluminum |
| Glass Type | High-Transparency Low-Iron Tempered Glass |
| Module Dimensions | 67.9 x 30.24 x 1.57 in (1725 x 768 x 40 mm) |
| Wind Load | 2,400 Pa |
| Snow Load | 5,400 Pa |
| Hazardous Location Rating | Class I, Division 2, Groups A, B, C & D |
| Module Fire Performance | Type 1 (US) |
| Fire Resistance Rating | Class C (Canada) |
| PV Module Application Class | Class A |
| Temperature Code Rating | T3C |
| Certification | cULus (File No. 272637) |
| Product Warranty | 10 Years |
| Power Warranty | 25 Years (Linear) |
