Unleash the Power with the Predator Raptor PRL-06

The Predator Raptor PRL-06 is an advanced 12.8V Lithium Iron Phosphate (LiFePO4) motorcycle and powersport starting battery, engineered to deliver high cranking performance, intelligent battery management and significantly reduced weight compared with conventional lead-acid batteries.

Delivering 180CCA, 6Ah capacity and 72Wh of power, the PRL-06 provides dependable starting performance in a compact battery weighing approximately 1kg. Its LiFePO4 chemistry offers excellent stability, low self-discharge and up to three times the cycle life of an equivalent lead-acid battery.

Intelligent Integrated BMS

The PRL-06 features a fully integrated Battery Management System (BMS) that actively monitors and protects the battery against abnormal voltage, current and temperature conditions.

Bluetooth connectivity allows the battery to communicate with the Predator Raptor App, giving users access to battery information and configurable intelligent operating features.

Intelligent Hibernation & Power Reserve

One of the standout features of the Predator Raptor range is its Intelligent Mode.

When configured through the Bluetooth app, the battery can automatically enter hibernation when preset conditions are reached. It can also hibernate as it approaches its discharge limit, helping preserve sufficient energy to start the vehicle when the battery is reactivated.

This makes the PRL-06 particularly useful for motorcycles, ATVs, personal watercraft and other powersport vehicles that may remain unused for extended periods.

Shake to Wake Technology

Predator's Shake to Wake technology makes reactivating a hibernating battery simple.

Movement of the vehicle can wake the battery from hibernation, eliminating the need to physically access the battery to reactivate it. This is especially convenient when the battery is installed beneath a motorcycle seat or in another difficult-to-access location.

HyperFlex Fitment System

The HyperFlex Fitment System allows one PRL-06 to replace several conventional motorcycle battery sizes.

The battery uses quad terminals – two positive and two negative – together with EVA height spacers, providing greater flexibility when matching the battery to different motorcycles and powersport applications.

With the supplied spacers, the standard 93mm battery height can be increased to approximately 105mm or 110mm where required.

Lightweight Starting Power

At approximately 1kg, the PRL-06 offers a substantial weight saving over many comparable lead-acid motorcycle batteries.

Despite its compact size and low weight, it produces 180 Cold Cranking Amps, providing strong starting performance for compatible motorcycles and powersport vehicles.

Key Features

• Advanced Lithium Iron Phosphate LiFePO4 chemistry
• 12.8V nominal voltage
• 6Ah capacity
• 180CCA starting performance
• 72Wh energy capacity
• Fully integrated Battery Management System
• Bluetooth connectivity with Predator Raptor App
• Intelligent automatic hibernation
• Shake to Wake technology
• HyperFlex Fitment System
• Quad terminal configuration
• EVA height spacers
• Low self-discharge
• Higher cranking power than equivalent lead-acid batteries
• Up to 3× the cycle life of equivalent lead-acid batteries
• Maintenance-free and spillproof construction
• IP65-rated battery case
• Compact and lightweight design
• Suitable for motorcycles and a range of powersport applications

Technical Specifications

Battery Replacements / Cross Reference

The Predator Raptor PRL-06 is designed to replace a range of common motorcycle and powersport battery sizes, including:

• YTZ10S / MBTZ10S
• YTX9-BS / MBTX9U – using the 12mm spacer
• YTZ12S
• YTZ14S / YTZ14-BS
• MBTZ14S – using the appropriate 12mm + 5mm spacers

Always confirm the original battery dimensions, terminal orientation, charging system requirements and vehicle manufacturer's specifications before installation.

Ideal Applications

The PRL-06 is suited to compatible motorcycles, road bikes, sports bikes, dirt bikes, ATVs, quad bikes, scooters, jet skis and other powersport equipment requiring a compact, lightweight battery with high starting performance.

For vehicles that aren't used every day, the combination of Intelligent Hibernation, Shake to Wake and low self-discharge makes the PRL-06 particularly useful for helping preserve battery power during periods of storage.
