LuxpowerTek SNA 6K Off-Grid Inverter
£306.00
Sale price
£306.00
Regular price
Skip to product information
LuxpowerTek SNA 6K Off-Grid Inverter
£306.00
Sale price
£306.00
Regular price
Shipping calculated at checkout.
SNA 6K
- ✔ Premium Quality Materials
- ✔ Quality Checked Before Dispatch
- ✔ Secure Payments
- ✔ Dedicated Customer Support
Fast Shipping
Quick dispatch and reliable delivery.
Secure Checkout
Your payments are protected and encrypted.
Easy Returns
Hassle-free return process.
Trusted Quality
Premium products loved by customers.
Don't Forget To Explore More From This Collection
Customers often buy these together to complete their project.
Description
LuxpowerTek SNA 6K Off-Grid Inverter
- 6kW single phase off-grid inverter for sites with weak, unreliable or no grid supply.
- Intelligent off-grid and hybrid modes, with seamless switching and wide PV input voltage range.
- Scalable design – support for up to 16 units in parallel for systems from 3kW to around 50kW.
Overview
The Fogstar x LuxpowerTek SNA 6K Off-Grid Inverter is part of the SNA 3–6kW series, designed for areas where grid power is unstable or scarce. It can operate as a pure off-grid inverter or in hybrid mode, supporting solar and utility jointly taking the load and allowing you to choose between self-consumption and charge-priority operation.
The SNA 6K supports paralleling of up to 16 inverters, enabling systems from 3kW to 50kW for residential, agricultural and small commercial applications. It provides seamless off-grid switching, a separate generator port and good battery compatibility with 48V lithium-ion and lead-acid batteries.
Key features
- Intelligent off-grid and hybrid modes with seamless switching between sources.
- Wide PV input voltage range with dual MPPT, and support for single phase or unbalanced 3‑phase systems via parallel operation.
- Separate generator port and host inverter auto-generation to manage multi-inverter systems.
- Compatible with lithium-ion and lead-acid batteries at 48V nominal, including force wake-up from PV and grid.
- Compact wall-mount design (303 × 505 × 135 mm) with LCD+LED display and RS485/Wi‑Fi/CAN communications.
Typical applications
Suitable for off-grid homes, cabins and holiday lets, farms, remote workshops and telecoms sites where diesel generators are currently used. It can act as backup power or replace generators, using solar and batteries to reduce running costs and noise.
Technical specifications
PV input (DC)
| Max. PV array power (W) | 8000 (4000/4000) |
| Rated PV input voltage (V) | 320 |
| Number of independent MPPT inputs | 2 |
| PV input voltage range (V) | 100–480 |
| MPPT voltage range (V) | 120–385 |
| Start-up voltage (V) | 100 |
| Max. PV input current per MPPT (A) | 17/17 |
| Max. PV short-circuit current input per MPPT (A) | 25/25 |
Battery
| Compatible battery type | Lithium-ion / Lead-Acid |
| Rated battery voltage (V) | 48 |
| Battery voltage range (V) | 38.4–60 |
| Max. charging/discharging current (A) | 26.5 |
| Max. discharging/charging power (W) | 6000 |
| Recommended capacity of battery per inverter | >200AH |
| Force wake up battery from PV function | YES |
| Force wake up battery from Grid function | YES |
Grid / AC input
| Rated AC voltage (V) | 230 |
| Rated AC frequency (Hz) | 50/60 |
| Rated AC output current (A) | 26.5 |
| Rated AC output power (W) | 6000 |
| Max. AC input current (A) | 39.5 |
| Max. AC input power (W) | 9000 |
| PF | 0.99 |
| THDI | <5% |
| Rated AC current of BYPASS relay (A) | 40 |
UPS / output
| Rated output power (W) | 6000 |
| Rated output voltage (V) | 230 |
| Rated output current (A) | 26.5 |
| Rated output frequency (Hz) | 50/60 |
| Surge power, duration | 2Pn, <2S |
| Switching time | <15ms@Single / <30ms@Parallel |
| Wave form | Sine wave |
| THDV | 3% |
Efficiency
| Max. MPPT efficiency | 99% |
| Max. efficiency | 0.99 |
| EU efficiency | 0.93 |
| Max. charging efficiency | 0.93 |
| Max. discharging efficiency | 0.93 |
Protection
| Over current/voltage protection | YES |
| AC short-circuit current protection | YES |
| Grid monitoring | YES |
| AC surge protection | Type III |
| Battery reverse polarity protection | YES |
General
| Dimensions (W × H × D) | 303 × 505 × 135 mm / 11.9 × 19.9 × 5.3 inch |
| Weight | 14.5 kg / 32 lbs |
| Ingress protection rating | IP20 |
| Operating environment temperature range | 0–50°C |
| Storage temperature range | -15–60°C |
| Relative humidity | 5%–95% |
| Display & communication interface | LCD+LED, RS485 / Wi‑Fi / CAN |
| Warranty | 2 years |
| Cooling method | FAN |
| Topology | Transformer-less |
| Altitude | <2000 m |
| Noise emission (typical) | <50 dB |
| Standards & Certification | IEC 62109-1, IEC 62109-2, IEC 61000 |
Documents available for download
- LuxpowerTek SNA 3–6k Single Phase inverter specification (datasheet) – includes full technical data for the SNA 6000W model.
- LuxpowerTek SNA 3–6k installation and user manual – follow for installation, commissioning and safety instructions.
Shipping
Available to the UK, Ireland, Africa, the Caribbean and worldwide. If the shipping rate is not shown at checkout, contact us on +44 2080640335 or info@energian.co.uk for a quote.
UK expert support
UK expert support is available for off-grid and hybrid system design, battery sizing, generator integration and inverter selection. Contact us via phone, email or live chat, or visit our office for an in-person consultation. For most projects we recommend installation by a qualified electrician or one of our trusted installer partners.
Suggested meta description: Fogstar x LuxpowerTek SNA 6K Off-Grid Inverter – 6kW 48V single phase inverter with intelligent off-grid and hybrid modes, wide PV input range and support for up to 16 units in parallel, with UK expert support and worldwide shipping.
