Description
l Multi-user management enables the effective management of each user's workload and resource consumption.
l It features comprehensive self-diagnosis capabilities and a built-in error inquiry function, which greatly facilitates maintenance and repair work.
l After one time measurement, you can freely switch the position of the applied weights between the 12 o'clock and 6 o'clock position. This feature also makes rim inner cleaning and the application of sticking weights more convenient.
l The "rotating wheel input" function enables rapid function selection and parameter setting.
l The built - in economical mode saves balance weights and time.
l There are four cones made of precision - machined, hardened steel.
l A self-calibration function is for the shaft and adaptors.
l Conduct a precision check of the rim runout and condition and provide a quantitative report.
Technical Date
| E31 | |
| Rim Diameter | 10"-32" |
| Rim width | 1.5"-25" |
| Maximum Tire Diameter | 46" |
| Maximum Tire Weight | 176lbs/80Kg |
| Accuracy | +/-1g(.0350z) |
| Placement Accuracy | 1. |
| Cycle Time | 6S |
| Rotation Speed | 200rpm |
| Power Supply | 110V/60HZ/1PH |
| Motor Power | 0.25KW |
| Shaft Diameter | 40mm/1.58" |
| Standard Cones Quantity Diameter Range | 4 pcs/1.8"-5.25" |
| Distance Between the Flange and the Body | 10.8"/275mm |
| Package Dimensions | 960*750*1130 |
Configuration
| Model | E31 |
| Wheel guard | YES |
| Automatic gauge A/D | YES |
| Automatic gauge B | YES |
| Automatic locating and locking unbalanced position | YES |
| Laser indicator for inner 12 o'clock position | YES |
| Laser indicator for inner 6 o'clock position | YES |
| Display | LCD |
| Lighting | YES |
| Rim runout diagnosis | YES |
| EALU function | YES |
| Calibration, self diagnosis, setting up functions | YES |
| Wheel locking method | By nut |
