Features

Efficient Solar Charging

• Advanced 3-Stage PWM Charging: Boost, Float, and Equalization charging; Equalization helps prevent sulfation in lead-acid batteries (excluding GEL and lithium).

• Automatic Temperature Compensation: Automatically adjusts charging voltage based on ambient temperature (-3.0 mV/°C/2V; excludes lithium).

Flexible System Compatibility

• 12V/24V Auto Detection: Automatically detects 12V or 24V battery systems.

• Supports Multiple Battery Types: Compatible with Sealed, GEL, Flooded, and lithium batteries.

• 55V Max Solar Input Voltage: Supports solar panel configurations with up to 55V PV input.

Safe & Reliable Operation

• Five Operating Modes: Light Control (10-min Delay), Light Control + Timer Control (1–14 h), Manual, Debug, and Normal On.

• Electronic Protection: Protects against overcharge, over-discharge, overload, short circuit, and reverse polarity.

• TVS Lightning Protection: Helps protect the controller from lightning-induced voltage surges.

• UL 1741 Certified: Certified for trusted safety and reliable performance.

Specifications

• Rated Current: 30A
• System Voltage: Auto recognition: 12V / 24V (Manual setup optional)
• Rated Power: 450W @12V / 900W @24V
• Max. Solar Input Voltage: < 55V
• Max. Battery Voltage: < 34V
• No-load Loss: <13mA @12V / <15mA @24V
• Battery Compatibility: Lithium/Sealed/GEL/Flooded
• Operating Temperature: –13°F to +131°F (–25°C to +55°C)
• Protection Rating: IP30 (Dust/Splash Resistant)
• Grounding: Positive Ground
• Dimensions: 164×103×47mm (6.46×4.07×1.85in)
• Net Weight: 0.39kg (0.86lb)
• Package Dimensions: 8 × 6 × 4 in

• Gross Weight: 2 lb
