Amptron 30A 12V/24V Inline AM MPPT Bluetooth Solar charge controller with Anderson Connection
£69.00
Sale price
£69.00
Regular price
£108.00
Skip to product information
SPECIFICATIONS
Amptron 30A 12V/24V Inline AM MPPT Bluetooth Solar charge controller with Anderson Connection
£69.00
Sale price
£69.00
Regular price
£108.00
Shipping calculated at checkout.
AT-SOLCHR-AM2430PV01
- ✔ Premium Quality Materials
- ✔ Quality Checked Before Dispatch
- ✔ Secure Payments
- ✔ Dedicated Customer Support
Fast Shipping
Quick dispatch and reliable delivery.
Secure Checkout
Your payments are protected and encrypted.
Easy Returns
Hassle-free return process.
Trusted Quality
Premium products loved by customers.
Don't Forget To Explore More From This Collection
Customers often buy these together to complete their project.
Projecta IS1400 12V 1400A Intelli-Start Professional Lithium Jump Starter and Power Bank
£170.00
Add to Basket
Description
This is an advanced high-efficiency and ultra-fast Multi-peak Maximum Power Point Tracking (MPPT) solar charge controller with built-in Bluetooth. The controller is customisable and compatible with several battery types including Lithium Iron Phosphate (LiFePO4) batteries. The controller supports historical data storage to provide comprehensive monitoring of your solar system.
The Maximum Power Point Tracking algorithm increases the energy efficiency, typically 15% to 20% higher than traditional PWM charging efficiency.
FEATURES
This is an advanced high-efficiency and ultra-fast Multi-peak Maximum Power Point Tracking (MPPT) solar charge controller with built-in Bluetooth. The controller is customisable and compatible with several battery types including Lithium Iron Phosphate (LiFePO4) batteries. The controller supports temperature compensation and historical data storage to provide comprehensive monitoring of your solar system.
The Maximum Power Point Tracking algorithm increases the energy efficiency, typically 15% to 20% higher than traditional PWM charging efficiency.
- The controller is compatible with Sealed Lead Acid, Gel, AGM, and Lithium Iron Phosphate batteries.
- Fast MPPT starts with ultra-fast sweeping of the entire V-I curve.
- Smart MPPT algorithm ensures better tracking in multiple power points.
- High PV harvest performance in weak sunlight conditions, advanced multi-peak tracking can accurately track the optimum power with partial shading.
- Excellent peak efficiency exceeds 98%.
- Bluetooth + Android & IOS App available.
- Support automatic identification of battery voltage.
- Overrating electronic components to minimize the power loss from heating, full charge power output up to 45ºC.
- LCD screen displays key operating information and facilitates parameter settings.
- Advanced protection for battery charging & discharging.
- Built-in over-temperature protection mechanism. The charge current and load will be decreased with temperature increase to reduce the controller’s temperature rise.
- Extensive electronics protections including PV reverse polarity & reverse current protection.
- Supports historical data storage with 300 days of data logging.
SPECIFICATIONS
| Item | Specification | Description/Remark |
| Model | AT-SOLCHR-AM2430PV01 | 30A12V/24V Inline MPPT Solar Charge Controller – Lithium compatible |
| Battery System Voltage | 12V/24V | |
| No-load Loss | 20ma (12V), 12ma (24V) | |
| Max. Solar input voltage | 30Voc (12V batteries) 50Voc (24V batteries) | |
| Rated charge current | 30A | |
| Max. usable Photo-voltaic system input power | 450W/12V 900W/24V | |
| Operating Temperature | -20ºC to +45ºC | |
| Internal Temperature Protection | -40ºC to +80ºC | |
| IP Protection | IP45 | |
| Product dimensions | L-150mm x W-80mm x H-35.3mm | |
| Weight | 350g | |
| BATTERY VOLTAGES | Flooded Lead Acid | Sealed Lead Acid | Gel (Default) | User (adjustable) | Lithium (adjustable) |
| Equalize Charge Voltage | 14.8V*n | 14.6V*n | – | Default: GEL | – |
| Boost Charge Voltage | 14.6V*n | 14.4V*n | 14.2V*n | Default: GEL | Default: 14.2V*n |
| Float Charge Voltage | 13.8V*n | 13.8V*n | 13.8V*n | Default: GEL | – |
| Boost Charge Recovery Voltage | 13.2V*n | 13.2V*n | 13.2V*n | Default: GEL | – |
| Over-discharge Recovery Voltage | 12.6V*n | 12.6V*n | 12.6V*n | Default: GEL | – |
| Over-discharge Voltage | 11.1V*n | 11.1V*n | 11.1V*n | Default: GEL | Default: 11.1V*n |
| Auto Temperature Compensation | -3mV/2V/℃ | -3mV/2V/℃ | -3mV/2V/℃ | Default: GEL | – |
